CONDON ENGINEERING Ltd

Cattle Cubicles – Cow Mats – Drinkers – Feeders – Cattle Gates.

Welcome to Condon Engineering based in County Louth in the north east of Ireland.

We specialise in Livestock Housing Solutions. We have been designing, manufacturing and supplying quality & innovative products to the agriculture sectors for over 30 years. All our products are manufactured at our state of the art premises and are manufactured to the highest specifications.

We pride ourselves in the quality of our work and ensure that our customers needs are exceeded.

Our business has grown from a small family run business into a larger operation that can manufacture a wide range of products.We are always looking to expand our product range so please don’t hesitate to contact us to discuss your requirements and to see how we can be of service.

We have a large variety of products from

COW CUBICLES   Adjustable Cantilever Cubicle

The adjustable cantilever cubicle has been successfully used for many years. As the cubicle is fitted to two support rails the height and width are easily adjusted.The cubicles allow space sharing whilst keeping the cow square, preventing soiling of the bed. The cubicles can be fitted in single or head to head rows.

Available in     Standard neckrail which has a neckrail height of 1100mm (44in)   High neckrail which has a neckrail height of 1250mm (49in)

Post Mounted Cantilever Cubicle

The post mounted system is more cost effective than the adjustable system. However, only the cubicle height can be adjusted as the cubicle is fitted directly to the post. The cubicles can be fitted in single or head to head rows.

Available in Standard neckrail which has a neckrail height of 1100mm (44in)   High neckrail which has a neckrail height of 1250mm (49in)

2-D super-space

The 2-D super-space cubicle provides more freedom than the standard 2-D cubicles and is appropriate for larger holstein cows. The cow can stand or lie down without being hindered by rails. However, the cubicle provides enough control so that she will lie straight and not soil the cubicle bed. The bottom support rail is positioned at ground level, thus moving it away from animals lunge zone The bottom support rail has a double function. In addition to supporting the cubicle it acts as a brisket pipe. The upper support rail is positioned high enough not to interfere with the lunge zone yet still low enough to prevent walk through.

Head to Head adjustable cantilever

DRINKERS

Condon Engineering offer a large range of cattle drinkers

Fresh, clean drinking water is vital for the health of animals.Contamination with manure and feed waste affect the smell and taste of the water. A dairy cow requires 4 to 5 litres (1 gallon) of water to produce 1 litre of milk. During the Summer months a high yield cow can consume up to 180 litres (40 gallons)of water per day.Cows drink on average 5 to 8 litres per minute. Drinkers need to be assessible from 3 sides and therefore ideally should not be placed in a corner.

Our drinkers are available in both galvanised steel and stainless steel

Different mounting systems are available including Wall mounted drinker Tip-over •Floor mounted



FEEDING BARRIERS

Condon Engineering offer a comprehensive range of feed barriers to suit any requirements  Barriers are available in standard and made to measure sizes Barriers are available with or without bases Barriers can be fixed or hinged

DIVIDING GATES

Condon Engineering offer a complete range of dividing gates for yards and cattle sheds.

CHEMICAL STORAGE

Chemical stores can be supplied as part of the farm office or in a seperate unit. They include: Two tier shelving Galvanised walkway mesh 200mm (8in) deep bunded floor under the walkway mesh Painted internally and externally.

FARM OFFICES

We manufacture a range of Farm Offices. They can have a range of options / extras as per your requirements.

MEAL BIN

Condon Engineering manufacture a fully galvanised meal bin with a 5.5 tonne capacity.Dual filling: Blown in from truck Filled with loader

The clearance from the outlet pipe to the ground is adjustable up to 900mm (3ft). The maximum distance from the top of meal bin to the ground is 3500mm (11ft 6in). Different legs lengths are available on request.
